Creating a filesystem in the browser

Recently I have been both creating and maintaining zesterer’s programing language tao playground that you can check out at https://tao.jsbarretto.com/. One of the new features that is coming is a module system, the module system allows better code organization by splitting your code into virtual units called 🥁 modules. A single file is a module (some languages can have multiple modules per file) and you can get the public exports from other modules.

#The problem

Only problem is that the playground only supports one file right now, heck even that isn’t true it’s just a single text editor from where the code is directly extracted. If you look at other languages playgrounds, you might notice that they normally don’t have multiple files support, but I want it so I’ll have it.

There’s actually a file and directory entries api but it’s non standard and only chromium based browsers seems to support it (you can check it here https://caniuse.com/#feat=filesystem) 😢, so we’ll need to roll out our own solution.

Note: Capucho from the future here, the caniuse link that I used is actually the wrong one, the correct one is https://caniuse.com/mdn-api_filesystem and this one shows that it’s supported by most browsers, so if you’re planning to do something similar to what’s described in this article consider using this api instead, continue reading if you want to explore a little about indexedDB.

#Alternatives

So the filesystem api is out, we need to find another way to store large-ish amounts of data in the browser and make it accessible from javascript, and our options are indexedDB and … wait, what do you mean indexedDB is our only option? Well I guess indexedDB it is.

#indexedDB

indexedDB is as the name says a database that works with unique indexes, compared with others web apis it’s fairly low level but it can quickly and efficiently handle large amounts data, just remember that it’s bound by the browser eviction criteria so don’t store data that you can’t risk to lose, use instead a backend with a real database for that.

#Opening the DB

Now that we know what we’ll be using let’s start coding. The first step to use the indexedDB api is opening a DB, this is akin to opening a database connection to a real DB except that you actually create the DB if it doesn’t exist. So first we want to get the indexedDB object but it might not be available in every browser or use a prefix (all major browsers have a prefix-less object, some older browsers have it exposed with a prefix, the prefix implementations might not be complete or may not work at all so for the sake of our mental sanity we’ll use only the prefix-less object), so let’s define a quick check to see if indexedDB is available.

if (!window.indexedDB) return; // 😢 No indexedDB for us

Now that we know that it’s available, let’s open the DB.

var db;
var request = indexedDB.open("TestDatabase", 1);

The star of the show here is the open method it takes a string and an integer as arguments (we can omit the integer if we don’t need versioning), the string is the database name and the integer is the version of the database (It is an integer, if you use a float it will be implicitly cast to an integer, rounding it and causing all sorts of trouble). We also define a variable that we will use later to store our database connection.

NOTE: The MDN documentation about using indexedDB (great resource about pratical use of the API, available at https://developer.mozilla.org/en-US/docs/Web/API/IndexedDB_API/Using_IndexedDB) , warns to not define any var indexedDB if not inside a function.

All operations on indexedDB are asynchronous (not your standard Promise though, it’s a IDBRequest 🤷‍♂️) and so we need to add two callbacks to our request, onsuccess and onerror, onsuccess will be called if everything goes well and contain the database in the object passed as the first argument to the callback under .target.result, onerror will be called if there’s any problem, proper error handling won’t be covered in this article.

// In case something goes boom
request.onerror = function (event) {
  console.log(event); // Do proper error handling kids
};

// In case everything goes 🥳
request.onsuccess = function (event) {
  // Assign to the variable we created earlier it will come in handy later
  db = event.target.result /* event.target.result contains the database */;
};

So now we have our database, but that isn’t all, we need to add a third callback to our request, onupgradeneeded, this callback is called both when we first create the DB and when we upgrade (i.e. increase our version number, downgrading is not allowed and will cause an error) and it’s also where we can define and upgrade our database schema, the database schema consists of stores and indicies, stores are responsible for holding the data while indicies are created per store and can be used to speed up queries, in our case we’ll only need to create one store.

request.onupgradeneeded = function (event) {
  // `onsuccess` will be called afterwards so we don't need to save
  // the database to the global we defined earlier, nonetheless we will
  // need to call some methods on the database right now so we create a
  // `let` binding to avoid having to type `event.target.result` everytime
  // we need access to it.
  let db = event.target.result;

  // Finally create the store
  var objectStore = db.createObjectStore("files", { keyPath: "path" });

  // You could also create other stores and indicies to those stores
};

The important bit here is createObjectStore, it takes two arguments a name and an optional options object with two fields, keyPath and autoIncrement, if we use keyPath we need to define a index manually for each object (We want this in our store because we will use the path of the file to index into it), in contrast autoIncrement works like SERIAL in sql increasing the key automatically.

Note: when upgrading, all stores will remain so you only need to create new ones or delete existing stores

And thats it for the DB setup, so now let’s focus on adding and retrieving data from it.

#Adding files

Right now our filesystem is pretty much useless, after all what good is it a filesystem if it can’t store files? To fix this let’s define a new function createFile, this function will be responsible for creating new empty files, a bit like touch in unix systems.

function createFile(path) {
  // ...
}

Our function will take a fully qualified path from root (I didn’t tell you but we’ll cheat by not defining folders) and create a new object in the DB, this object will contain the path in the filesystem and the data of the file which will be empty.

// We start by creating a transaction object spanning the `files` store
// and having read/write access to it
let filesObjectStore = db
  .transaction("files", "readwrite")
  // Get a reference to our object store
  .objectStore("files");

// Our "file" is just a js object with two keys, one for the path
// and another for the data
let file = {
  // The path will be our index and we will use it for querying later
  path: path,
  // The data is a Blob, it will be initialized empty and with a MIME type of text/plain
  data: new Blob([], { type: "text/plain" }),
};

// Finally add to the file to our store
let add = filesObjectStore.add(file);

// Don't forget everything is asynchronous, so we need to define callbacks
add.onsuccess = function (event) {
  console.log("File added 😎");
};

To do any operation on a indexedDB we need to create a transaction, to create one we use the db method transaction, it takes an array of strings or a string as it’s first argument, this is the list of object stores our transaction will span across, the smaller it is, the less stores will be locked while performing the transaction, allowing for faster transactions, so only declare the stores that are absolutely needed. Next we define our mode this can either be readonly or readwrite, the former can be faster but only the latter can mutate data, as such doing a readonly transaction and mutating data will cause an error to be signaled.

The call will return a IDBTransaction object, we can call the objectStore method on it to get a reference to the object store and proceed to call add with our file to add our file to the store.

Once again all this interface is callback based so it will only be completed when onsuccess is called. But you may notice we omitted the onerror callback.

Like most errors in JS, the errors produced in indexedDB do what it’s called bubbling, this means that they will go up the error chain until they find a error handler in this case it is from add -> indexedDB -> browser this means that having a handler in indexedDB is enough to catch the errors without it reaching the browser, in a real scenario error handling should be done as close to the source as possible.

Our file structure is very simple, we just have a path that we use as the key to our file, and the file data that we store as a Blob, for our purposes a string would have been enough as we only store text, but by using Blobs it’s also possible to store binary data, as such you can add whatever data you want later on and even embed other metadata like creation time, not to mention adding download functionality becomes easier (But that’s beyond the scope of this post).

#Querying files

We can now create files in our virtual filesystems, but we cannot yet retrieve them, so to fix that we’ll implement two functions, one to get a single file by it’s path and another to get all the files present in the filesystem.

#Single file

The first function is going to be called getFile and it will take one argument, the full path to the file we want to retrieve, and it will return a promise that will resolve to the text stored in the file.

function getFile(path) {
  return new Promise((resolve, _) => {
    // We create a transaction that will work on our files object store
    let filesObjectStore = db
      // We won't write to the store so we can use readonly
      .transaction("files", "readonly")
      // Get a reference to our object store
      .objectStore("files");

    // Queue the operation to get the file on the store
    let get = filesObjectStore.get(path);

    // Don't forget everything is asynchronous, so we need to register
    // a callback for when the operation finishes
    get.onsuccess = function (event) {
      // To actually read the file we use the FileReader interface
      const reader = new FileReader();

      // FileReader is asynchronous, as such we need to listen for the `loadend`
      // event that will be fired when it finishes loading and parsing the `Blob`
      reader.addEventListener("loadend", (e) => {
        const text = e.srcElement.result;
        // Signal that the promise is finished and pass the parsed text
        resolve(text);
      });

      // Read our blob of data as a string
      reader.readAsText(event.target.result.data);
    };
  });
}

The first thing to note, is the fact that all the logic is wrapped in a unnamed function that’s passed to the Promise constructor, this function is passed two other functions as it’s inputs, the first when called resolves the Promise and the second signals an error to the consumers of the Promise.

This allows us to adapt the callback style of the indexedDB to the more modern Promise interface allowing us to await on it.

Inside the unnamed function, we start by creating our transaction and getting a reference to the store like in createFile, but this time we create the transaction as readonly since we don’t need to mutate the store.

Then we call get on the store with the path of our file, as always we need to register the onsuccess callback, the callback will have our file object in the first argument under .target.result.

Since we stored the data as Blob but want to return a string we need to use the FileReader api to convert from a blob to a string to do so we use the readAsText method, the FileReader api signals completion with events, in this case we listen to the loadend event that will be fired when the conversion finishes. The callback to this event will contain the text as a string in the first argument under .srcElement.result

Finally, we call the resolve method, provided by the Promise function, with the text we just decoded to signal the consumers that it’s finished.

#All files

Next we want to define a function to get all the files currently stored in our virtual filesystem, to do so we’ll define the getAllFiles function.

function getAllFiles() {
  return new Promise((resolve, _) => {
    // We create a transaction that will work on our files object store
    let filesObjectStore = db
      // We won't write to the store so we can use readonly
      .transaction("files", "readonly")
      // Get a reference to our object store
      .objectStore("files");
    // Queue the operation to get all the files in the store
    let getAll = filesObjectStore.getAll();
    // Don't forget everything is asynchronous, so we need to register
    // a callback for when the operation finishes
    getAll.onsuccess = function (event) {
      resolve(event.target.result);
    };
  });
}

The code is very similar to getFile, only instead of calling get with the path to the file, we just call getAll, and we don’t do any processing of the result.

#Updating files

We almost have a working filesystem we are just missing a way to update the files, since empty files aren’t a whole lot useful, let’s introduce the updateFile function to do so.

function updateFile(path, text) {
  // We create a transaction that will work on our files object store
  let filesObjectStore = db
    // We will write to the store so we must use readwrite
    .transaction("files", "readwrite")
    // Get a reference to our object store
    .objectStore("files");
  // To update our file we define one with the same path but with the new data
  let file = {
    path: path,
    // Our new data, text is wrapped in brackets because all Blobs
    // need to have it's part be a sequence
    data: new Blob([text], { type: "text/plain" }),
  };
  // Finally put the updated file on the store
  let put = filesObjectStore.put(file);
  // Don't forget everything is asynchronous, so we need to register
  // a callback for when the operation finishes
  put.onsuccess = function (event) {
    console.log("File updated 😎");
  };
}

The code is almost identical to that of creating a file, except that this time we put some data in the file and use put instead of add, this will overwrite the file with the new data (if we had used add we would get an error about the key already existing).

#Deleting files

We can now do everything that was required by the project, we can create, read and update files, but as a bonus let’s also add a way to delete the files, so for the last time lets define a new function, deleteFile.

function deleteFile(path) {
  // We create a transaction that will work on our files object store
  let filesObjectStore = db
    // We will write to the store so we must use readwrite
    .transaction("files", "readwrite")
    // Get a reference to our object store
    .objectStore("files");
  // Delete the file from the store
  let delete = filesObjectStore.delete(path);
  // Don't forget everything is asynchronous, so we need to register
  // a callback for when the operation finishes
  delete.onsuccess = function(event) {
    console.log("File deleted 😎");
  };
}

The code is very simple, we create a readwrite transaction to the files store, and call delete on the object store passing the path of the file, and that’s it.

#Fin

That was one hell of a ride, but now we have a virtual file system running in the browser (it isn’t really a file system but serves a similar purpose).

There’s no error reporting so things like path collisions won’t be handled, and instead will throw errors to the console, but it should be enough to get you started, if you want to learn more about indexedDB then take a look at the mdn docs.

See you next time.
